DNCKE-.../KEC-...
Festo DNCKE-.../KEC-... 0204NH English
34
12 Technical specifications
Type DNCKE-40-... DNCKE-63-... DNCKE-100-...
KEC-16-... KEC-20-... KEC-25-...
Mounting position As desired
Medium Filtered (40 µm) compressed air, lubricated or non-
lubricated
Operating pressure range Clamping unit: min. 3.8 ... max. 10 bar
Cylinder: min. 0.6 ... max. 10 bar
Rod diameter [mm]
16
h7...f7
20
h7...f7
25
h7...f7
Rod quality – Hardened (min. HRC 60) or hard-chromium plated
(thickness of layer min. 20 µm)
– S urface roughness R
t
less than 4 µm
– T olerance range of the rod diameter h7...f7
– 3 mm wide 15° chamfer on the end of the clamping
rod
Static holding force 1300 N 3200 N 8000 N
Permitted temperature range - 20 ... max. + 80 °C
Materials Housing: Al
Piston rod: St (hard-chromium plated)
Tie rods, collar nuts: St
Seals: Buna N
Weight (approx.)
– KEC-...
– DNCKE-... (basic weight)
– DNCKE-... (per 10 mm stroke)
1.9 kg
2.3 kg
0.045 kg 4.5 kg
5.5 kg
0.073 kg 16.8 kg
18.2 kg
0.11 kg
Fig. 30
