4-32

5708009-C

Advanced Energy

®

WIRING DIAGRAMS FOR OPTION E USER PORT

The diagrams in this section provide wiring information to properly connect to the
Apex 15-pin User port configuration E.

14

MODULE STATUS

LED OUTPUT

(AMBER)

Digital

output

This pin provides the
output for remote
DeviceNet LED and is
connected to the emitter of
an opto-coupler. The User
must limit the current
draw through this pin to
45mA or less.

Note: Defined by

DeviceNet
Specification,
Release 2.0

See Wiring Diagram 4-24.

15

NETWORK STATUS

LED OUTPUT

(AMBER)

Digital

output

This pin provides the
output for remote
DeviceNet LED and is
connected to the emitter of
an opto-coupler. The User
must limit the current
draw through this pin to
45mA or less.

Note: Defined by

DeviceNet
Specification,
Release 2.0

See Wiring Diagram 4-24.

Table 4-3. User Port (15-pin) Connector Pins Exclusive for Configuration E (Continued)

Signal

Pin

Return

Pin

Name

Signal

Type

Description
