5708009-C

3-7

Apex 1 to 5.5 kW Generator

Full-rated output power

(Minimum into a 50

Ω, non-

reactive load)

Note: Varies according to the

option defined by PIN
position 2.

A—1000 W

B—1500 W

C—2000 W

D—3000 W

E—4000 W

F—5500 W

J—5000 W

K—1000 W high accuracy low output (HALO)

L—1500 W HALO minimum into a 50

Ω, non-reactive

load

M—3500 W

Output impedance

Note: Varies according to the

option defined by PIN
position 9.

A—50

Ω

B—exclusive option #1

C—exclusive option #2

D—exclusive option #5

E—exclusive option #6

F—exclusive option #3

G—exclusive option #4

H—exclusive option #7

J—exclusive option #8

Delivered power into 2:1
VSWR loads

Note: Varies according to the

option defined by PIN
position 2.

B—1.5kW = 1125W

D—3kW = 2000W

F—5.5kW = 3350W

Delivered power into 3:1
VSWR loads

Note: Varies according to the

option defined by PIN 2.

B—1.5kW = 650W

D—3kW = 1200W

F—5.5kW = 1900W

Table 3-3. Output Specifications (Continued)

Description

PIN Option and Specification
