1-6 5708009-C
Advanced Energy
®
5 Panel 0—none (on-board, frame mount)
1—integrated rack mount with blank panel
2—integrated rack mount with passive digital display
(see “Apex Status Indicators (LEDs)” on page 4-79)
3—N/A
4—exclusive option #1
For panel illustrations, see “Apex Panel Illustrations” on
page 4-80.
6 Serial I/O 0—default (RS-232 with AE Bus) (see “Host Port—RS-
232 With AE Bus” on page 4-37)
1—Multidrop RS-485 with AE Bus (Currently NOT
available)
2—DeviceNet (see “Host Port—DeviceNet” on page 4-72)
3—Profibus (see “Host Port—Profibus” on page 4-58)
4—exclusive option #1
5—DeviceNet (serial)
6—exclusive option #3
7—exclusive option #2
7 Serial Port 2 0—default (no secondary serial port)
1—RS 232
2—RS 485
Table 1-1. Apex PIN Positions and Associated Options (Continued)
PIN
Position
Apex Feature Options, Descriptions, and Cross-References
