4-30 5708009-C
Advanced Energy
®
6 SIGNAL COMMON Chassis
ground
Common for signal pins 2,
3, and 5. Connected to the
Apex generator chassis
ground.
7 8 RF ON STATUS Digital
output
When an RF ON
STATUS condition is
detected, a low (opto-
coupler output)
impedance is created
between this pin and pin 8
(6mA max).
See Wiring Diagram 4-29.
8 RF ON STATUS
RETURN
Digital
output
See pin 7
9 +15 Vdc Voltage
reference
+15 Vdc provided to the
User port through a 1.1k
Ω
resistor. Can be used for a
switch or relay contact
closure to enable RF ON
(pin 4).
See Wiring Diagram 4-30.
10 MODULE STATUS
LED OUTPUT
(GREEN)
Digital
output
This pin provides the
output for remote
DeviceNet LED and is
connected to the emitter of
an opto-coupler. The User
must limit the current
draw through this pin to
45mA or less.
Note: Defined by
DeviceNet
Specification,
Release 2.0
See Wiring Diagram 4-24.
Table 4-3. User Port (15-pin) Connector Pins Exclusive for Configuration E (Continued)
Signal
Pin
Return
Pin
Name Signal
Type
Description
