1-8 5708009-C
Advanced Energy
®
11 Output connector 0—exclusive option #1
1—7/16 connector)
2—SQS

connector
3—LC connector
4—HN
5—N
6—exclusive option #2
For further information see “Connecting Output Power” on
page 5-5.
12 RF measurement 0—directional coupler
1—V/I sensor
13 AC power input A—ODU connector (see “ODU Connector” on page 5-7)
B—Non-terminated 3 m, 4-conductor, shielded pigtail
(see “NonTerminated, four-Conductor Pigtail” on page 5-8)
C—Non-terminated 12
′
, 4-conductor, pigtail (see
“NonTerminated, four-Conductor Pigtail” on page 5-8)
D—Harting Type Han-Q (see “Harting Type Han-Q
Connector” on page 5-9)
E—4-terminal, stud mount
F—15´ 4-conductor, with a Hubbell CS8365C plug
G—5´ Harting
H—Term 3m, 4 cond, shielded pigtail Marinco 3015P
J—5’ terminated, 4 conductor, SH with contact LS1
BF.F6 5+PE (30A)
K—ODU connector with 20 degree rotation
L—Harting Type Han-Q (16A) rotated 180 degrees
M—6’,4 conductor with #10 ring lugs on each wire
14 Pulsing 0—no pulsing
1—pulse (see “Understanding and Setting Up Pulsing
Output” on page 5-13)
Table 1-1. Apex PIN Positions and Associated Options (Continued)
PIN
Position
Apex Feature Options, Descriptions, and Cross-References
