5708009-C 4-75
Apex 1 to 5.5 kW Generator
.
Note: For information on LED flash rates, refer to section 8.2.8 of the DeviceNet
Specification (revision 2.0).
Note: For information about Module Status LED indications during power-up, refer to
Section 8.2.4 of the DeviceNet Specification (revision 2.0).
Devicenet Network Status LED
The NET bi-color (amber/green) LED indicates the status of the communication link.
The following table shows the LED’s various states and their meanings.
Table 4-14. MOD Status LED
LED State Meaning
Off No power the unit is not receiving
power.
Green (steady) Operational the unit is operating
normally.
Flashing Green Standby the unit needs maintenance
because the configuration is
missing, incomplete, or
incorrect.
Amber Unrecoverable Fault the unit has experienced a
fault from which it cannot
recover; you may need to
replace the unit.
Flashing Amber/Green Device Self-Testing the unit is running self
diagnostics
Table 4-15. Network Status LED
LED State Meaning
Off No power The unit is not on-line
because:
• it has not completed the
Dup_MAC_ID test yet
• it is not receiving
power (check the MOD
LED).
Green (steady) Link okay The unit is on-line and
allocated to the master
