5708009-C
1-7
Apex 1 to 5.5 kW Generator
8
User port options
A—no User port
B—25-pin APEX standard (see “25-Pin Apex Standard
User Port” on page 4-2)
C—25-pin custom RFG compatible
D—15-pin, exclusive option #2 (see “15-Pin User Port
(Exclusive—Option D)” on page 4-16)
E—15-pin, exclusive option #3 (see “15-Pin User Port
(Exclusive—Option E)” on page 4-26)
F—N/A
G—exclusive option #4
9
Output
impedance
A—50
Ω
B—exclusive option #1
C—exclusive option #2
D—exclusive option #5
E—exclusive option #6
F—exclusive option #3
G—exclusive option #4
H— exclusive option #7
J—exclusive option #8
10
On-board RF
output connector
location
0—opposite end from water connections
1—utilities end (near water connections)
Table 1-1. Apex PIN Positions and Associated Options (Continued)
PIN
Position
Apex Feature
Options, Descriptions, and Cross-References
