5708009-C 5-9
Apex 1 to 5.5 kW Generator
Table 5-3 provides pin descriptions for the nonterminated, four-conductor input
options.
HARTING TYPE HAN-Q CONNECTOR
The following section describes the Harting Type Han-Q input connector. To
determine if your Apex unit has this connector, use the configuration PIN from your
Apex unit and the following Configuration Note.
This section of the manual provides information for the:
Nonterminated, four-conductor pigtail input options
PIN position13, (A 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17) options B and C
(When identifying the PIN position, remember that the A at the beginning of the
PIN is not counted as a position. The PIN option is the number or letter you
should look for in the specified position.)
For more information about the PIN and for a complete list of how PIN positions
correspond to Apex product options, see Table 1-1. on page 1-4.
Table 5-3. Nonterminated, Four-Conductor Pin Descriptions
Pin Description
1 Phase (black)
2 Phase (black)
3 Phase (black)
Ground Green or Green/yellow stripe
This section of the manual provides information for the:
Harting Type Han-Q input connector
PIN position13, (A 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17) option D.
(When identifying the PIN position, remember that the A at the beginning of
the PIN is not counted as a position. The PIN option is the number or letter
you should look for in the specified position.)
For more information about the PIN and for a complete list of how PIN
positions correspond to Apex product options, see Table 1-1. on page 1-4.
