5708009-C 4-69
Apex 1 to 5.5 kW Generator
162
read process
status
Requests report on process status; returning
packet contains the following bytes arranged
as follows.
1st status byte:
0 = unassigned
1 = unassigned
2 = unassigned
3 = unassigned
4 = unassigned
5 = output power (0 = off, 1 = on)
6 = unassigned
7 = setpoint status (0 = within tolerance,
1 = out of tolerance)
2nd status byte:
0 = end of target life
1 = unassigned
2 = unassigned
3 = overtemperature
4 = unassigned
5 = unassigned
6 = unassigned
7 = interlock open
3rd status byte—fault flags:
0 = nonmaskable interrupt
1 = bus fault
2 = high bus voltage
3 = unassigned
4 = low bus voltage
5 = out of setpoint
6 = unassigned interrupt
7 = unassigned
4th status byte—fault flags:
0 = current limit
1 = contactor failure
2 = unassigned
3 = unassigned
4 = unassigned
5 = unassigned
6 = unassigned
7 = CEX is locked
4 data bytes
four 8-bit
values
Table 4-11. Profibus Host Port Commands (Continued)
Command Description Number of
Transmit
Data Bytes
Number of
Response
Data Bytes
