Apex 1 to 5.5 kW Generator
4 6 RF POWER
ENABLE Digital
input
RF output is enabled when a 4 to
30 V input (pin 9, RF ON BIAS,
can be used as a voltage source)
is present on this pin.
Note: The interlocks must be
satisfied and the setpoint
must be within the Output
power range before unit
will deliver power. See
Table 3-3. on page 3-6 for
the Output power range
specification.
See Wiring Diagram 4-17.
5 6 FORWARD/LOAD
POWER SETPOINT Analog
input
This analog signal provides a
linearly scaled control of the
forward or load output power
depending on the regulation
mode (1 V per 1 kW output
power).
See Wiring Diagram 4-16.
Note: The interlocks must be
satisfied and the setpoint
must be within the Output
power range before unit
will deliver power. See
Table 3-3. on page 3-6 for
the Output power range
specification.
6 SIGNAL COMMON Chassis
ground
This pin is Signal Common. Also
connected to Apex generator
chassis ground.
7 6 RF ON STATUS Digital
output
+ 5 Vdc on this pin represents
RF ON.
See Wiring Diagram 4-18.
8 6 EXTERNAL BIAS Voltage
reference
+15 Vdc provided to the User
port through a 5.62 k
Ω resistor.
See Wiring Diagram 4-20.
Table 4-2. User Port (15-pin) Connector Pins Exclusive for Configuration D (Continued)
Signal
Pin
Return
Pin
Name Signal
Type
Description
