5708009-C 1-5
Apex 1 to 5.5 kW Generator
3 Input voltage 0—208 V nominal, 187 to 229 Vac, 3
φ, 47 to 63 Hz, with
breaker
1—400 V nominal, 360 to 440 Vac, 3
φ, 47 to 63 Hz, with
breaker
2—reserved
3—208 V nominal, 187 to 229 Vac, 3
φ, 47 to 63 Hz,
without breaker
4—400 V nominal, 360 to 440 Vac, 3
φ, 47 to 63 Hz,
without breaker
5—220,208 to 229 Vac, 1 phase, 47/63 Hz w/o breaker
For more information on input voltage and other
specifications, see “Electrical Specifications” on page 3-5.
4 Packaging A—frame mount (
≤
5500 W)
B—frame mount with rack ears (1/2 rack) (utilities)
C—integrated rack mount
D—1/2 integrated rack mount (left)
E—1/2 integrated rack mount (right)
F—exclusive option #1
G—exclusive option #2
H—exclusive option #3
J—exclusive option #4
K—on board frame mount, opposite end LED’s
L—on board frame mount, opposite end LED’s w/4
handles
M—on board frame mount, opposite end LED’s w/2
handles
N—frame mount w/ rack ears (1/2 rack) (opposite)
Table 1-1. Apex PIN Positions and Associated Options (Continued)
PIN
Position
Apex Feature Options, Descriptions, and Cross-References
