Table 4-1. User Port 25-Pin APEX Standard Pin Descriptions

Signal

Pin

Return

Pin

Name

Signal

Type

Description

1

SETPOINT STATUS
RETURN

Digital
Output

See signal pin 14

2

15

RFL PWR
MONITOR

Analog

output

This signal provides a linearly
scaled read back of reflected
power.

0 to 10V = 0 to maximum rated
power output as defined by
configuration PIN in Table 1-1
position 2 in Table 1-1.

See Wiring Diagram 4-2.

Pin 15 must be grounded.

3

16

FWD/LOAD PWR
MONITOR

Analog

output

This signal provides a linearly
scaled read back of forward
power when the generator is
operated in forward power
regulation mode or the load
power when operated in the load
power regulation mode.

0 to 10V = 0 to maximum rated
power output as defined by
configuration PIN position 2 in
Table 1-1.

See Wiring Diagram 4-1. for
wiring diagram.

Pin 16 must be grounded
