Allied Telesyn

AT-VIEW PLUS

DEVICE MANAGEMENT

Displays the RMON History table.


Alarm Table

Displays the RMON Alarm table.

Event Table

Displays the RMON Event table.


Event Log

Displays the RMON Event log.

Port Menu

From the Port menu, you can view and edit MIB information about the port.

Utilization

Displays the port's utilization information.


Interface Info

Displays port statistics such as the number of frames received and transmitted on the port,
bytes received and transmitted on the port, and port status.

Note

- Valid MIB Set values for the Administration Status parameter are 'up' and 'down'.

Attempting to set this parameter to any other value will result in the error message: "The
error occurred with 'Set' operation. Error: gen Error."

Detail Info

Displays detailed port information such as duplex mode.

Note

- The Port Name parameter is not applicable to the AT-9410GB.

Note

- The current firmware version does not allow the Port VLAN Tag Priority parameter to

be configured. Attempting to configure this parameter will result in the error message: "The
error occurred with 'Set' operation. Error: bad value."

Note

- The Port Transmit Pacing Configuration parameter is not applicable to the AT-

9410GB.

Note

- AT-View Plus Device Manager allows the user to disable an active port. However, the

disabled port's Port Link State parameter retains the value 'on-line'.

Note

- When connection is established between a twisted pair port that is configured to auto-

negotiate and a port on another device that is configured to operate at 10/100Mbps full/half
duplex, expect the link to drop when the twisted pair port's speed and mode is changed to
match the speed and mode of the port on the other device.

PN 613-50507-00 Rev D

Page 82 of 253
