At-ar022, At-ar023, At-ar024 – Allied Telesis AT-VIEW PLUS 2.4 DEVICE MANAGEMENT User Manual
Page 245: At-ar026, At-ar022 at-ar023 at-ar024 at-ar026

Allied Telesyn
AT-VIEW PLUS
DEVICE MANAGEMENT
Device Manager LEDs for AT-AR021(S) and AT-AR021(U)
LED
State
Description
B1 and B2 Green
Gray
For permanent circuits, HDLC packets are being exchanged between the
switch or router and another end system device (normally another switch or
router) over any of the B channel. For on-demand ISDN, there is a call up
over the respective B-channel.
No packet/data transmission over B-channel.
AT-AR022
Note
- There are no LEDs on this PIC.
AT-AR023
Note
- There are no LEDs on this PIC.
AT-AR024
Note
- There are no LEDs on this PIC.
AT-AR026
Device Manager LEDs for AT-AR026
LED
State
Description
DUPLEX Green
The port is operating at full-duplex.
PN 613-50507-00 Rev D
Page 245 of 253
