Allied Telesyn AT-VIEW PLUS
DEVICE MANAGEMENT
Forwarding Database
Displays the Forwarding Database table.
Discard/Aging Time Info
Displays information about the number of address entries that were learned but discarded
because either there was a lack of memory or the entry's aging timer expired.
Spanning Tree Info
Displays spanning tree parameters such as priority and cost.
Statistics
Displays statistics about frames received/transmitted on the switch port.
Port Menu
From the Port menu, you can view and edit MIB information about the port.
Utilization
Displays the port's utilization information.
Interface Info
Displays port statistics such as the number of frames received and transmitted on the port,
bytes received and transmitted on the port, and port status.
Error Statistics
MAU Info
Displays the MAU's auto-negotiation settings and its status.
Displays error statistics.
Spanning Tree Info
Displays the port's spanning tree parameters.
Displays interface-related MAU information for the port.
MAU Negotiation Info
Enable
Enables the port.
Disable
Disables the port.
AT-9812T
PN 613-50507-00 Rev D Page 201 of 253
