Port Interface Cards
This section describes the following Port Interface Cards supported in AT-View Plus Device
Manager :
AT-AR020
•
•
AT-AR021
•
AT-AR022
•
AT-AR023
•
AT-AR024
•
AT-AR026
•
AT-AR027
If one of these PICs is installed in a PIC bay of a Router (AT-AR400 series or AT-AR700 series), or
in a
of a Router or Layer 3 Switch (Rapier series), it is displayed in
the PIC bay of the device in the main window. The operations available for the main device include
the ports in any of these PICs.
AT-AR020
Device Manager LEDs for AT-AR020
LED
State
Description
B Data
Green
Gray
HDLC packets are being exchanged between the switch or router and
another end system device (normally another switch or router) over any of
the B (data) channels.
No packet transmission over B channel.
AT-AR021
