Allied Telesyn

AT-VIEW PLUS

DEVICE MANAGEMENT

AT-9410GB

This section describes AT-View Plus Device Manager menus and operations specific to the AT-
9410GB switch.

Topics:

Main Window

Agent Menu

Bridge Menu

RMON Menu

Port Menu

Main Window

AT-9410GB

Device Manager LEDs for AT-9410GB

LED

State

Description

PWR

Green

The switch is receiving power.

DUPLEX Green


Orange

The port is operating at full-duplex mode.

The port is operating at half-duplex mode.

Note

- When Global STP is enabled, the current firmware version sets the Port State parameter of

PN 613-50507-00 Rev D

Page 79 of 253
