Device Manager LEDs for AT-A19

LED

State

Description

DUPLEX Green

Orange

The port is operating at full-duplex.

The port is operating at half-duplex.

AT-A16/AT-A17/AT-A19

Device Manager LEDs for AT-A16/AT-A17/AT-A19

LED

State

Description

DUPLEX Green

Orange

The port is operating at full- duplex.

The port is operating at half-duplex.

AT-A45/AT-A47/AT-STACKM

Note

- There are no LEDs on this module.

AT-A46

Device Manager LEDs for AT-A46

LED

State

Description

DUPLEX Green

Orange

The port is operating at full-duplex.

The port is operating at half-duplex.
