94 AR700 Series Router User Guide
Software Release 2.7.1
C613-02047-00 REV A
higher the path cost, and the lower the traffic over the interface.) Enter the
commands:
add dvmrp interface=eth0 metric=1
add dvmrp interface=ppp0 metric=6
add dvmrp interface=ppp1 metric=3
Configure multicast routing using DVMRP on Router B.
1. Set the system name.
To set a unique system name for the router, enter the command:
set sys name=b-dvmrp
2. Configure PPP.
To create a PPP interface over a synchronous port, enter the command:
create ppp=0 over=syn0
3. Configure IP.
To enable IP on the router, and assign IP addresses to the interfaces used by
DVMRP for multicast routing, enter the commands:
enable ip
add ip interface=ppp0 ipaddress=189.124.7.8
mask=255.255.0.0
add ip interface=eth0 ipaddress=172.74.1.2
mask=255.255.255.0
add ip interface=eth1 ipaddress=172.74.2.2
mask=255.255.255.0
4. Configure IGMP.
To enable IGMP on the router, and on the interfaces that have IP host
connected to them, so that the router can maintain its group membership
data, enter the commands:
enable ip igmp
enable ip igmp interface=ppp0
enable ip igmp interface=eth0
enable ip igmp interface=eth0
5. Configure DVMRP
To enable DVMRP on the router and on each interface over which it is used
for multicast routing, enter the commands:
enable dvmrp
add dvmrp interface=eth0 metric=1
add dvmrp interface=eth1 metric=1
add dvmrp interface=ppp0 metric=6
Configure multicast routing using DVMRP on Router C.
1. Set the system name.
To set a unique system name for the router, enter the command:
set sys name=c-dvmrp
