104 AR700 Series Router User Guide
Software Release 2.7.1
C613-02047-00 REV A
Routing Information Protocol (RIP)
The Routing Information Protocol (RIP) is a distance vector protocol that is part
of the TCP/IP protocol suite used to exchange routing information between
routers. RIP determines a route based on the smallest hop count between
source and destination.
To enable RIPv2 on the Eth port 0, enter the command:
add ip rip interface=eth0 send=rip2 receive=both
To display information about RIP ( Figure 18 ), enter the command:
show ip rip
Figure 18: Example output from the SHOW IP RIP command.
To interpret output from the SHOW IP RIP command see the Internet Protocol
(IP) chapter in the Software Reference.
Resource Reservation Protocol (RSVP)
The Resource Reservation Protocol (RSVP) is a signalling protocol designed to
reserve bandwidth for realtime transmission. RSVP is not a traffic delivery
protocol or a routing protocol. RSVP does not deliver the application’s traffic to
its destination or manage the routing of the data packets; this is left to existing
transport and routing protocols.
RSVP enables the receiver of a traffic flow to make the resource reservations
necessary to ensure that the receiver obtains the desired Quality of Service
(QoS) for the traffic flow.
RSVP is disabled by default. To enable RSVP, enter the command:
enable rsvp
Each IP interface that is to receive and process RSVP messages and accept
reservation requests must be enabled. To enable RSVP on Eth port 0, enter the
command:
enable rsvp interface=eth0
To display information about the interfaces enabled for RSVP ( Figure 19 ), enter
the command:
show rsvp interface
Figure 19: Example output from the SHOW RSVP INTERFACE command.
Interface Circuit/DLCI IP Address Send Receive Demand Auth Password
-------------------------------------------------------------------------------
eth0 - - RIP2 BOTH NO NO
ppp0 - 172.16.249.34 RIP1 RIP2 YES PASS ********
-------------------------------------------------------------------------------
RSVP Interfaces
Maximum Reserved No. Of
Interface Enabled Bandwidth(%) Bandwidth(%) Reservations Debug Encap
------------------------------------------------------------------------------
Dynamic No 75 0 0 None RAW
eth0 Yes 75 0 1 None RAW
ppp0 Yes 75 0 0 None RAW
------------------------------------------------------------------------------
