103
Software Release 2.7.1
C613-02047-00 REV A
3. Associate RIP and SAP filters with IPX circuit
To associate the RIP and SAP filters with the IPX circuit over the PPP link,
enter the command:
set ipx circ=2 ripchange=yes sapchange=yes outrip=0
outsap=0
4. Save configuration
To save the new dynamic configuration as a script, enter the command:
create config=ipxfilt.scp
AppleTalk
The AppleTalk network architecture provides internetworking of Macintosh
computers and other peripheral devices using LocalTalk media. AppleTalk
allows seamless access to network services such as file servers and printers
from the Macintosh desktop environment. The open nature of the architecture
has enabled the AppleTalk network system to extended support to other media
types (for example EtherTalk for Ethernet media), and a mixture of both Apple
and non-Apple network devices on the same AppleTalk network.
To create an AppleTalk port (interface) associated with Eth port 0, enter the
command:
add apple port interface=eth0
To display information about the ports configured for AppleTalk ( Figure 17 ),
enter the command:
show apple port
Figure 17: Example output from the SHOW APPLE PORT command.
To interpret output from the SHOW APPLE PORT command see the AppleTalk
chapter in the Software Reference.
Appletalk Port Details
------------------------------------
Port Number .............. 1
Interface ................ eth0
ifIndex .................. 1
Node ID .................. 217
Network Number ........... 22
Network Range Start ...... 22
Network Range End ........ 22
State .................... ACTIVE
Seed ..................... NO
Seed Network Start ....... 0
Seed Network End ......... 0
Hint ..................... YES
Hint Node ID ............. 179
Hint Network ............. 22
Default Zone ............. -
Zone List is Empty
------------------------------------
