100

AR700 Series Router User Guide

Software Release 2.7.1
C613-02047-00 REV A

1.

Configure the PPP Link

Refer to other sections of this guide on how to configure PPP interface 0 on
each router to use the wide area link.

See

“Point to Point Protocol (PPP)” on page 70

for information about

configuring PPP to use a synchronous link.

See

“Configuring ISDN” on page 76

for information about configuring

PPP to use an ISDN call.

If the PPP interface is configured for dial-on-demand operation (see

“Configuring ISDN Dial on Demand” on page 81

) or bandwidth on

demand operation (see

“Configuring ISDN Bandwidth on Demand” on

page 82

), these services are automatically used by the IPX routing

software.

2.

Configure IPX Routing

To purge the IPX static database to clear any pre-existing IPX configuration
and enable the IPX routing software on each router, enter the commands:

purge ipx

enable ipx

On the Head Office router define two IPX circuits, one for the Ethernet
interface and one for the wide area link, by entering the commands:

add ipx circ=1 int=eth0 netw=401 encap=802.3

add ipx circ=2 int=ppp0 netw=129

To repeat this procedure on the Remote Office router, defining one IPX
circuit for the Ethernet interface and one for the wide area link, enter the
commands:

add ipx circ=1 int=eth0 netw=12 encap=802.3

add ipx circ=2 int=ppp0 netw=129

The routers are now configured for IPX and can exchange routes and service
information.

3.

Test the Configuration

To examine the route table and service table on each router, enter the
commands:

show ipx route

show ipx service

The route table will contain paths from each Novell device which advertises
routes, for example file servers and routers. The service table lists all the
services, such as file services and print services, that devices are advertising.

The actual contents of the route table varies with the number and type of file
servers present on the network. A route from each router to the other, and all
services shown as local (i.e. via eth0) on one router, should also be visible on the
other router, via the PPP link.

Test that a workstation on the Remote Office LAN can login to the file server
on the Head Office LAN.

4.

Save the Configuration

Save the new dynamic configuration as a script, by entering the command:

create config=ipxconf.scp
