The intended target rate
Note: If a prescription is loaded, P is displayed to indicate that the prescription rate is being
used, rather than the Target 1 rate ( T )
6 Application Control menu quick access icon
7 Information tab listing sprayer−specific information
Quick access icon
The icon enables you to access the most common variable rate controller settings more quickly. When you
select the icon, the following screen appears:
Alternatively, set the User Mode to Advanced and then select Configuration / Application Control.
Using the Rawson Controller
When using a Rawson variable rate controller with the EZ−Guide 500 lightbar, note the following:
Default rate and step size
The values entered for Default Rate and Step Size on the EZ−Guide 500 lightbar must match the values entered on
the Rawson controller when they are first plugged in.
Target rate
37
