ITEM DESCRIPTION
1 EZ−Guide 500 lightbar
2 Ag 15 antenna
3 Antenna cable (PN 50449)
4 EZ−Guide 500 power cable (PN 62817)
5 To power
6 EZ−Guide 500 AUX port cable (PN 62609)
7 Serial port extender cable (PN 63076)
8 Rawson (COM A) to EZ−Guide 500 cable (PN 69730)
9 Rawson Controller
Note: The target rate information from the EZ−Guide 500 lightbar is sent to both drives on the Rawson
controller.
Radar speed input
Radar input is required for speed. You can connect either an external radar device, or use cable PN 54806−00, as
shown below.
