Hardi 5500 Variable Rate Controller
Connecting a Hardi 5500 Controller
Connect the Hardi 5500 variable rate controller to the EZ−Guide 500 lightbar COM port as shown below.
ITEM DESCRIPTION
1 EZ−Guide 500 lightbar
2 Ag15 antenna
3 Antenna cable (PN 50449)
4 EZ−Guide 500 power cable (PN 62817)
5 To power
6 Hardi 5500 (COM1) to EZ−Guide 500 cable (PN 59043)
7 Hardi 5500 Controller
Note: The Hardi 5500 controller must have firmware version 3.16 or greater installed and have a JOBCOM
control box connected for it to work correctly with the EZ−Guide 500 lightbar.
