Rawson Variable Rate Controller
Connecting a Rawson Controller
Connect the Rawson variable rate controller to the EZ−Guide 500 lightbar COM port as shown below.
ITEM DESCRIPTION
1 EZ−Guide 500 lightbar
2 Ag 15 antenna
3 Antenna cable (PN 50449)
4 EZ−Guide 500 power cable (PN 62817)
5 To power
6 Rawson (COM A) to EZ−Guide 500 cable (PN 69730)
7 Rawson Controller
Connect the Rawson variable rate controller to the EZ−Guide 500 lightbar AUX port as shown below.
31
