Alternatively, set the User Mode to Advanced and then select Configuration / Application Control.
Using the Hardi Controller
When using a Hardi variable rate controller with the EZ−Guide 500 lightbar, note the following:
Boom setup
If the boom setup differs between the EZ−Guide 500 lightbar and the Hardi controller, a warning message appears
on the lightbar. You must configure the EZ−Guide 500 lightbar to match the Hardi controller. To do this, select
Configuration / Application Control / Boom Setup.
Rate control
The EZ−Guide 500 lightbar has two options for rate contol:
ITEM DESRIPTION
On
Application rates are sent from a prescription loaded in the EZ−Guide 500 lightbar or the target rate
manually configured on the lightbar.
Off
The target rate must be set on the Hardi controller. The EZ−Guide 500 lightbar does not send target rates
to the controller. (This is the default setting)
To configure the Rate Control option, select Configuration / Application Control / Rate Control .
20
