5
The intended target rate
Note: If a prescription is loaded, P is displayed to indicate that the prescription rate is being used,
rather than the Target 1 rate ( T )
6 Application Control menu quick access icon
7 Information tab listing sprayer−specific information
Quick access icon
The icon enables you to access the most common variable rate controller settings more quickly. When you
select the icon, the following screen appears:
Alternatively, set the User Mode to Advanced and then select Configuration / Application Control.
Using the Raven Controller
When using a Raven variable rate controller with the EZ−Guide 500 lightbar, note the following:
Target rate
To manually enter a rate to send to the controller, select Configuration / Application Control / Target Rate .
Automatic boom switching
The EZ−Guide 500 lightbar will not do automatic boom switching for the Raven variable rate controller.
29
