64 AutoSteer System
Hardware Components
Hardware Components
This section describes the hardware components that are shipped with each version of Repeater. An optional Tripod
(500-0163-01) for installing the repeater in portable applications and a 4 foot (1.2 Meter) pole section (500-0003-01) or 12
foot (3.6 meter) pole kit (200-0315-01) for installing the repeater in permanent installations are also available and can be
ordered separately to facilitate optional mounting situations.
A5 Repeater Components
The A5 Repeater components are shown in Figure 5-5 and defined in Table 5-1.
Figure 5-5 A5 Repeater Components
Table 5-1 Repeater Component Definitions and Part Numbers
Part Description Part Number
1. A5 Repeater Radio Modem 280-0004-01
2. Repeater Power Cable 201-0205-01
