Hardware Installation Manual

Installing and Powering ON the Base Station

3. After attaching all connectors to supply power to the Base Station, turn the power inverter’s power switch to the ON

position.

Note: Verify that all antennas and antenna cables have been installed and are properly mounted before supplying
power to the Base Station enclosure. Failure to do this may cause damage to the radio components.

Note: The Base Station begins transmitting RTK correction signals within a minute of powering up. Depending on the
firmware version loaded on the Base Station and the Base Station’s survey status, it may take 24 hours or more for the
Base Station to start transmitting absolute position fixes.

Note: The Base Station can be powered from a 12.0 volt battery if a 120 VAC power source is not available or a
power failure has occurred.

Note: To turn off the Base Station power, unplug the power connector from the bottom of the Base Station enclosure
or turn off the switch on the power inverter.
