Installing the AFLink Radio Modem

3. Install the earth ground per the local regulations that specify lightning protection grounding.

Note: Picture shows other connections already connected.

Installing the AFLink Radio Modem

1. Loosen the 2 - Phillips screws on clamps holding enclosure door closed. The screws are located on the right side of the

enclosure.

Note: The screws do not need to be completely removed. They can be loosened until the clamp can be slid from over
the lip holding the door closed.
