Ag Leader Base Station Hardware Manual User Manual
Page 23
Hardware Installation Manual
21
Hardware Setup
5. Attach the Male Quick-Release Coupler to the Tripod.
Note: This step can be skipped if the Male Quick-Release Coupler is stored attached to the Tripod.
6. Mount the Base Station on top of the Tripod by connecting the Female Quick-Release Coupler to the Male Quick-Release
Coupler.
