Mount Radio Modem Antenna
Note: The Radio Modem Antenna can move slightly after being installed without having any effect on the
performance of the RTK system. Mounting this antenna on top of a radio tower or grain leg is acceptable to provide
maximum range.
Figure 4-7
Correct Base Station Radio Modem Antenna Positioning
Figure 4-8
Incorrect Base Station Radio Modem Antenna Positioning
3. Mount the Radio Modem Antenna.
