HP StorageWorks Simple SAN Connection Manager user guide
73
• To disallow access to individual HBAs, select each HBA in the Servers and HBAs/Initiators allowed
to have access to the selected Logical Disk list, and then click Remove.
• To disallow access to all of the HBAs and servers shown in the Servers and HBAs/Initiators allowed
to have access to the selected Logical Disk list, click Remove All.
NOTE:
If any server is designated as an Unknown Server, you may be unable to deny access to
that HBA or server (that is, you cannot remove it from the “allowed” list). For more information, see
The updated list of HBAs and servers allowed to have access to the LUN is listed under Servers and
HBAs/Initiators allowed to have access to the selected Logical Disk.
5.
(Optional) To manually give an HBA access to the logical drive:
a. On the Logical Disk Server Presentation dialog box, click Manual Add. The New HBA Port Names
dialog box opens; see
on page 64 (for EVA storage) or
on page 70 (for MSA
storage).
b. In the first box, enter the World Wide (WW) port name of the HBA. You can enter the HBA WW
port name formatted as either 20 consecutive alphanumeric characters, or as 10 two-digit segments
separated by hyphens; for example, xx-xx-xx-xx-xx-xx-xx-xx-xx-xx.
c. In the second box, enter the name of the server on which the HBA(s) are installed. If you do not
know the name of the server, enter Unknown.
d. When you finish manually adding the HBA, click OK to save the information and close the dialog
box. To close the dialog box without saving any data, click Cancel.
NOTE:
A map on the left side of the dialog box presents a graphical representation of access
assignments. HBAs that currently have access to the LUN (access is granted, as in
) are
designated with a solid blue line drawn between the HBA and the LUN. If this access is removed
(access is denied, as in
), the line is dotted red. If the HBAs currently have no access to the
LUN and access is granted, the line is dotted blue.
6.
Click Set Logical Disk Presentation.
7.
Click Close.
NOTE:
If you present (assign) a logical disk to a Windows system, use the system’s Disk Management
option to create partitions and assign a drive letter or mount path on partitions.
1.
To access Computer Management, choose one of the following options:
• Open the Windows Control Panel, select Administrative Tools, and then select Computer
Management.
• On the Windows desktop, right-click the My Computer icon, and then click Manage.
2.
In the Computer Management utility’s left pane under Storage, click Disk Management.
Expanding a logical disk
Simple SAN Connection Manager enables you to easily increase the size of logical disks within your SAN.
To expand a logical disk:
1.
To access the Expand Logical Disk dialog box, choose one of the following options:
• On the Logical Disk Operations menu, click Expand Logical Disk.
• In the navigation pane or the content pane’s LUN Assignment map, right-click the logical disk icon,
and then on the shortcut menu, click Expand Logical Disk.
