9.
Press
OK
to move the cursor to the next triplet. When the address is complete press
OK
to bring
up the confirmation screen.
10.
The graphical screen displays Yes. Press
OK
to save the configuration, or to delete and re-enter
another IP address, press
Left arrow
or
Right arrow
, which changes the display to No.
11.
After selecting the IP address, enter the subnet mask and default gateway by repeating steps 8–
10. To get subnet mask and default gateway information in Windows XP Pro:
1.
Click on Start, select All Programs, Accessories, then System Tools.
2.
Click System Information, Components, Network, then Adapter. The current PC settings
information is displayed. Obtain subnet mask and default gateway information.
12.
When all information is entered, the MFP may power cycle.
13.
If at any time during the configuration
Cancel
is pressed, the system exits the menu and the
addresses are not saved.
Automatic configuration
1.
On the control panel, press
Menu
.
2.
Press the navigation arrows to select Network config. then press
OK
.
3.
Press the navigation arrows to select TCP/IP configuration, then press
OK
.
4.
Press the navigation arrows to select Automatic, then press
OK
.
It can take several minutes before the automatic IP address is ready for use.
NOTE
To disable or enable specific automatic IP modes (such as BOOTP, DHCP, or AutoIP),
use options provided in the embedded Web server or HP ToolboxFX only.
Link speed settings
NOTE
Incorrect changes to the link speed and duplex settings might prevent the MFP from
communicating with other network devices. For most situations, the MFP should be left in
automatic mode. Also note that changes may cause the MFP to power cycle; makes changes
only while the MFP is idle.
1.
On the control panel press
Menu
.
2.
Press the navigation arrows to select Network config. then press
OK
.
3.
Press the navigation arrows to select Link speed, then press
OK
.
4.
Press the navigation arrows to select one of the following settings.
●
Automatic
●
10T Full
●
10T Half
●
100T Full
●
100T Half
