Displayed item
Description
No summary
displayed
Summary
displayed
•
vmwfixed: The Fixed algorithm (VMware)
•
vmwmru: The Most Recently Used algorithm
(VMware)
•
vmwrr: The Round Robin algorithm
(VMware)
•
unknown: An algorithm other than the above
VmPSP
#1
-
The PSP currently in effect.
VmRuntimeName
#1
-
In path information fields, displays the path
runtime information managed by VMware
vSphere.
VmState
#1
-
The path status managed by VMware vSphere.
•
active: Online
•
standby: Online
•
off: Offline status caused by a command
operation (Offline(C))
•
dead: Offline due to an error (Offline(E))
•
unavailable: Offline due to an error
(Offline(E))
•
perm_loss: Offline due to an error
(Offline(E))
Paths that are dead, unavailable, or perm_loss
require corrective action. The appropriate action
can be determined by referring to
.
-
Paths
Total number of the paths recognized by HDLM
for the LU to be displayed.
-
OnlinePaths
Number of available paths in the displayed
paths, indicated by a decimal number. When the
value of Paths equals the value of OnlinePaths,
all paths are online. If the value of OnlinePaths
is less than that of Paths, some paths are
offline. In this case, you should check the offline
paths and take appropriate action for any paths
that have an error status.
Legend:
- : Not displayed
#1
This information is displayed when one of the following conditions exist:
- The user selected the item to be displayed by using the -lu -item
parameter.
- all was specified.
- No value was specified for the parameter.
