the capacity of V-VOL. When there is no open system volume, No Volume is displayed.
•
The button displays the volume capacity information (capacity by volume type, pie chart, total
capacity) on zSeries, S/390 (mainframe), and multiplatform volumes in the storage system. The
displayed information does not include the capacity of V-VOL. When there is no zSeries and
S/390 volume, No Volume is displayed.
•
Pie chart and capacity by volume type when OPEN Volume is selected:
The following capacities are displayed in MB when the Total Volume Capacity is 10 GB or less.
The following capacities are displayed in GB, when the Total Volume Capacity is more than 10
GB. The percentages (%) of the following capacities relative to the total capacity of the open system
volumes are displayed in parentheses.
Open Volume Capacity Pie Chart
Description
Item
The capacity of open system volumes (LDEVs) that have assigned paths and are
available to the user. This capacity does not include control cylinders, reserved
volumes of Volume Migration, journal volumes, pool volumes, system disks, or
quorum disks. This capacity is indicated in the pie chart by the yellow area.
Allocated LDEV
Capacity
The capacity of open system volumes (LDEVs) that do not have assigned paths and
are available to the user. This capacity does not include control cylinders, reserved
volumes of Volume Migration, journal volumes, pool volumes, system disks, or
quorum disks. This capacity is indicated in the pie chart by the yellow area.
Unallocated LDEV
Capacity
The capacity of the following volumes among zSeries, S/390, and multiplatform
volumes (LDEVs). This capacity does not include reserved volumes of ShadowImage
for IBM z/OS.
• Reserved volumes of Volume Migration (for information on XP Auto LUN, contact
the Technical Support Center (see “
)
• Journal volumes (see the Universal Replicator for Mainframe User’s Guide)
• Pool volumes (see the XP Snapshot User’s Guide or XP Thin Provisioning User’s
Guide)
• Quorum disks (see the HP StorageWorks XP24000/XP20000 External Storage
Access Manager Software User’s Guide)
• System disks (see the Virtual LVI/LUN (VLL) & Volume Shredder User’s Guide)
This capacity is indicated in the pie chart by the pink area.
Reserved
Capacity
The sum of allocated and reserved volume capacities.
Total Volume
Capacity
Free space that users can use for configuring zSeries, S/390, and multiplatform
volumes (LDEVs). This is displayed in the pie chart by white area.
Free Space
Mainframe Volume Capacity Pie Chart
Description
Item
The capacity of zSeries, S/390, and multiplatform volumes (LDEVs) that have
assigned paths and are available to the user. This capacity does not include
reserved volumes of Volume Migration, volumes, system disks, or quorum disks.
This capacity is displayed in the pie chart by blue area.
Allocated LDEV
Capacity
