Description
Item
See “
License Key List
The Total Storage graphic is on the left of the License Key window, and displays the total
volume capacity currently available in the storage system.
Total Storage
Allows you to select one of the following modes for installing a license key.
•
When Key Code mode is selected, use the Key Code text box to type the license key
code for the selected option to be installed (see Enabling Options Using a License Key
Code). You cannot copy and paste text from other applications.
•
When File mode is selected, use the File Name text box or the Browse button to enter
the name of the license key file (see Enabling Options Using a License Key File). When
you click Browse, a dialog box opens allowing you to select the desired license key
file.
•
When Available mode is selected, you can install available options automatically.
The Available button can be used only when the licensed capacity exceeds the
mounted (or used) capacity because the disk drives are reduced, or because the pairs
are deleted by a program product such as XP Continuous Access.
License Install
Allows you to enable or disable each program product option listed in the license key
list. Select a program product option from the license key list, select Enable or Disable,
and click Set.
•
Enable: You can use the program product option. If you enable an option with the
term key, the available days of term key will lessen one day when you set Enable.
When the setting is applied, Installed appears.
•
Disable: You cannot use the program product option. If you disable an option with
the term key, the available days of term key will not lessen when you set Disable.
When the setting is applied, Installed (Disable) appears.
License Status
OPEN Drive Capacity displays the capacity of open system drives in the Total Storage.
Mainframe Drive Capacity displays the capacity of the mainframe drives in the Total
Storage.
The capacity of SATA or SSD drives in each capacity is displayed in parentheses.
Capacity
Information
Changes the row of the selected option or the options that can be installed using the
Available button to
blue bold italics and also changes the displayed status to Install.
NOTE:
The options are not actually installed until you click Apply.
Install button
Changes the row of the selected option to
blue bold italics and also changes the displayed
status to
Uninstall.
NOTE:
The options are not actually uninstalled until you click Apply.
Uninstall button
Applies the settings made using Install or Uninstall to the storage system. The status of
installed options changes to Installed, and the status of uninstalled option changes to Not
Installed.
Apply button
Cancels the settings made using the Install or Uninstall buttons.
Cancel button
