• LDKC:CU:LDEV column displays the LDKC number, the CU number, and the LDEV number. These
numbers are separated by colons (:).
• An LDEV number that ends with the pound or gate symbol (#) indicates that the LDEV is an
external volume (for example 00:00:01 #). For details regarding the external volumes, see the
HP StorageWorks XP24000 External Storage Software User's Guide.
• An LDEV number that ends with a "V" mark indicates that the LDEV is a Copy-on-Write Snapshot
virtual volume (for example 00:00:01 V). For details regarding virtual volumes, see the HP
StorageWorks XP24000/XP20000 Snapshot User's Guide.
• An LDEV number that ends with a "X" mark indicates that the LDEV is a Dynamic Provisioning
virtual volume (for example 00:00:01 X). For details regarding virtual volumes, see the HP
StorageWorks XP24000/XP20000 Thin Provisioning Software User's Guide.
• An LDEV number that ends with a "M" mark indicates that the LDEV is a migration volume (for
example 00:00:01 M).
The icons have the following meaning:
Table 19 Icons in the LDKC:CU:LDEV column
Description Icons
Normal LDEV
Expanded (LUSE) volume
Reserved volume of Auto LUN
Variable-sized volume (CV)
Secured LDEV
Remote command device
Command device
Command device to which the command device security is applied
• You can export the information displayed on the Reports Display dialog box as a CSV file using
the Export button on the lower left of the Reports Display dialog box.
To export the information displayed on the Reports Display dialog box as a CSV file:
• To export the information displayed on the Reports Display dialog box as a CSV file:
1. Click Export at the lower left of the Reports Display dialog box.
The dialog box for selecting file is displayed.
2. Specify the file name and location to save the file on the displayed dialog box.
3. Click Save.
When the save processing finishes, the procedure is completed.
• The Reports Display dialog box is closed when you click Close on the lower right of the Reports
Display dialog box.
XP24000/XP20000 Remote Web Console User's Guide 95
