Description Item
Displays the following when Fibre is selected in Type:
• SLPR: SLPR number and SLPR name.
• Port Name: Port name.
• Type: Type of port (Fibre).
• Host Speed: Data transfer speed, in Gbps (Gigabits per second), for Fibre Channel
ports.
• Addr. (Loop ID): Address and Loop ID of port.
• Fabric: Indicates whether a Fabric switch is used. Enable or Disable is displayed.
• Connection: Topology. FC-AL or P-to-P is displayed.
• Attribute: Port attribute. Initiator, Target, RCU Target, or External is displayed.
• WWN: WWN of DKC port.
Port list (when Fibre
is selected)
Displays the following when Serial is selected in Type:
• SLPR: SLPR number and SLPR name.
• Port Name: Port name.
• Type: Type of port (Serial).
• Attribute: Port attribute. LCP is displayed.
Port list (when Serial
is selected)
Displays the following when Mfibre is selected in Type:
• SLPR: SLPR number and SLPR name.
• Port Name: Port name.
• Type: Type of port (Mfibre).
• Attribute: Port attribute. HTP or FNP is displayed.
• WWN: WWN of Mfibre Port.
Port list (when Mfibre
is selected)
LUN Dialog Box
The information about the open-system volumes is displayed on the LUN dialog box. For more detailed
information about the displayed items, see the HP StorageWorks XP24000/XP20000 LUN Manager
User’s Guide.
XP24000/XP20000 Remote Web Console User's Guide 97
