Connected host dialog box (reports display) – HP StorageWorks XP Remote Web Console Software User Manual
Page 104

Figure 43 Connected Host Dialog Box (Reports Display)
The displayed items on the Connected Host dialog box are as follows:
Description
Item
You can select the LDKC for which information is to be displayed from the drop-down
list.
LDKC
You can select the CU for which information is to be displayed from the drop-down
list.
CU
The sequential number of the list.
No.
The type and the model number of a host (or a channel extender).
Type/Model
The node ID of a host (or a channel extender).
SEQNUMBER
A logical partition number of a host.
LPAR
Indicates the vendor of the host. This column can display FJT (Fujitsu), IBM, HTC (HP),
and CNT(Ex). If CNT(Ex) appears, the table row indicates the type, the model number,
and the node ID of a channel extender.
Vendor
Using the Remote Web Console GUI
104
