Server Power

Figure 7-3: System interconnect status LEDs

Item Description

1 System

interconnect

2

I/O board interconnect

3

Processor board 1 interconnect

4

Processor board 2 interconnect

7-6

HP ProLiant DL740 Server User Guide
