HP Storage Mirroring V4.5 Software - Manual (Page 35)

3 - 13
Connection settings
The Connection tab includes options that will be applied to the specified source/target connection.
Route
This setting identifies the Target IP Address that the Storage Mirroring data will be transmitted
through. You should only change this setting if you want to select a different route for Storage
Mirroring traffic. On a machine with more than one NIC, this increases the flexibility of configuring
Storage Mirroring activity. For example, you can separate regular network traffic and Storage
Mirroring traffic on a machine. The default ports will be used.
In a cluster, the route should be set to the name of the Exchange virtual server (EVS) dependent
IP address.
Protected Storage Groups
The Protected Storage Groups area displays the storage groups, mailbox, and public folder stores.
Select the Exchange storage groups that you want to protect. By selecting individual storage groups
to protect, you can reduce the amount of data being replicated and filter out storage groups that do
not need to be protected or failed over. Only the users associated with the selected storage groups
will be failed over. By default, all storage groups are selected for an Exchange source.
The replication set that the Application Manager generates will include the directories and files needed
to protect the selected storage groups. It is recommended that you protect all storage groups.
You can also select non-application specific data under the Volumes folder.
NOTE:

If you do not select all storage groups, you should make sure that other backups are
available from which to recover the storage groups that are not failed over.

Hewlett-Packard recommends that you place all query-based distribution groups in a
single organization container and give the target server full control rights to the
container and all child objects.
NOTE: If Override Generated Rules is selected on the Advanced tab, this control will be
disabled.
