Monitoring the System 115
M
onit
ori
ng
th
e Sys
tem
Viewing the Status Summary
Status summary lets you view overall environmental and activity status for the
NAS server, cluster components (if you have a high-availability NAS server),
and any attached storage arrays. If an environmental item is running out of
specification, a status symbol indicates the severity of the problem. The
following symbols are used in the tables in this tab:
: OK
: An item is non-critical but warrants attention
: An item is critical
: The status information could not be obtained
: Informational status only
You can click on an item in the table and select Actions > View Details to
view the specific environmental area, or you can make your selections from
the System Status tree.
To view the overall system status summary:
1 In the Command View NAS web interface, click the Status tab.
2 Navigate down the tree and select Status Summary.
The following status information appears for the NAS server:
■ Temperature
■ System voltages
■ Cooling fans
■ Memory
■ Power supplies
The following status information appears for the cluster if you have a high-
availability NAS server:
■ Nodes
■ Failover packages
At the top of the page, you can select a refresh rate (30 seconds to 5 minutes)
for the displayed information.
If you have any attached storage arrays, you can view the environmental and
performance status by clicking the array in the table and then selecting
Actions > Launch Command View SDM.
