www.milestonesys.com 172 Management Client elements
Generic event data source (properties)
Component Requirement
Data source
You can choose between two default data sources and define a
custom data source. What to choose depends on your third party
program and/or the hard- or software you want to interface from:
Compatible: Factory default settings are enabled, echoes all bytes,
TCP and UDP, Ipv4 only, port 1234, no separator, local host only,
current code page encoding (ANSI). Compatible with XProtect
Enterprise version 6.0 up to 8.x, but not with 2013 and later
versions.
International: Factory default settings are enabled, echoes
statistics only, TCP only, Ipv4+6, port 1235, as
separator, local host only, UTF-8 encoding. ( = 13,10).
[Data source A]
[Data source B]
and so on.
New Click to create a new data source.
Name Name of the data source.
Enabled
Data sources are by default enabled. Clear the check box to disable
the data source.
Reset
Click to reset all settings for the selected data source. The entered
name in the Name field remains.
Port The port number of the data source.
Protocol type selector
Protocols which the system should listen for, and analyze, in order
to detect generic events:
Any: TCP as well as UDP.
TCP: TCP only.
UDP: UDP only.
TCP and UDP packages used for generic events may contain
special characters, such as @, #, +, å, ~, etc.
IP type selector Selectable IP address types: IPv4, IPv6 or both.
Separator bytes
Select the separator bytes used to separate individual generic event
records. Default for data source type International (see Data
sources earlier) is 13,10. (13,10 = ).
