Thermo Fisher Scientific CyberScan pH 10/pH 100 - Manual (Page 63)

59
16 METER SPECIFICATIONS
SPECIFICATIONS pH 10 pH 100
pH Range 0.00 to 14.00 pH -2.00 to 16.00 pH
Resolution 0.01 pH 0.01/0.1 pH (Selectable)
Accuracy ± 0.01 pH ± 0.01/0.1 pH
Slope Range 80% to 120% 80% to 120%
Temperature Range 0.0 to 100.0 ºC 0.0 to 100.0 ºC
Resolution 0.1 ºC 0.1 ºC
Accuracy ± 0.5 ºC ± 0.5 ºC
Millivolt Range (400 mV) -400 to +400 mV -400 to +400 mV
Resolution 0.1 mV 0.1 mV
Accuracy ± 0.2 mV ± 0.2 mV
Millivolt Range (2000 mV) -2000 to +2000 mV -1600 to +1600 mV
Resolution 1 mV 1 mV
Accuracy ± 2 mV ± 2 mV
No. Of Calibration Points 1 to 3 points 1 to 5 points
No. Of pH Buffer Values 3 5
pH Buffer Options pH 4.01, 7.00, & 10.01 pH 1.68, 4.01, 7.00, 10.01, 12.45
Relative mV functions Yes
Relative mV offset display Yes
Slope Display Yes
Offset Display Yes
Memory 16 data sets
Outputs RS232C
Auto Shut-off Yes (20 minutes) Selectable
Averaging/Stability (READY) Yes Selectable
Display Dual LCD Dual LCD
Hold Function Yes Yes
ATC Function 0.0 to 100.0 C 0.0 to 100.0 C
Inputs BNC, Phono, Power jack BNC, Phono, Power jack
Power Requirements 4 ‘AAA’ Batteries; AC/DC Adapter
9 V, 500 mA
4 ‘AAA’ Batteries; AC/DC Adapter
9 V, 500 mA
Battery Life > 50 hours > 50 hours
Environmental Requirements 0 to 50 ºC 0 to 50 ºC
Operating Range 0 to 50 ºC 0 to 50 ºC
Dimensions; Weight Meter: 18 x 9 x 4 cm; 220 g
Boxed: 24 x 23 x 7 cm; 600 g
