Mode# Setting of the BCD Input BI Option
1 3 * This setting is necessary when BI option is chosen.
A B C D E F
1 3. 0 0 1
BCD Data Input Logic
0 : Hi Active (Each input terminal and GND are open.)
1 : Low Active (Each input terminal and GND are open.)
Latch Signal Input Logic
0 : Latch on short
1 : Latch on open
BCD Data Input selection
0 : Stall
1 : PRESET A
2 : PRESET B
Select of the BCD Data Input
Select BCD input for which preset.
Latch Signal Input Logic
Data is not input when latch signal is input.
0 : Latch on short - Data is not input when latch signal pin and GND are short.
1 : Latch on open - Data is not input when latch signal pin and GND are open.
BCD Data Input Logic
Setting of the Logic of BCD Data which is inputed.
0 : Hi Active - Data is input when each pin of input data and GND are open.
1 : Low Active - Data is input when each pin of input data and GND are short.
