OPTION NAME
Alarm output : Two-points NPN output : OUT 1,2
Alarm output : Two-points PhotoMOS relay
output : OUT 3,4
Blank 7 segments LED (RED)
RE 90° phase contrast input
RE-2T 90° phase contrast input (Input two multiplying)
RE-4T 90° phase contrast input (Input four multiplying)
AV3 Analog electric voltage output (DC1-5V, 5V-1V)
AV4 Analog electric voltage output (DC0-5V, 5V-0V)
AV5 Analog electric voltage output (DC0-10V, 10V-0V)
AI Analog electric current output (DC4-20mA, 20-4mA)
B* BCD output
BI* BCD input
Blank NPN Open collector pulse input
F Electric voltage pulse input
V3 Sinusoidal input
N Sine curve input
L1 Line receiver input, Single phase input
L2 Line receiver input, Double phase input
HI High speed input (0.01Hz-120kHz)
Blank DC12V stabilization
S24 DC24V stabilization
Blank AC Power source (AC85-264V)
DC DC Power source (DC12-24V)
About model type
e.g1) Choose analog electric current output, electric voltage pulse input and DC power supply.
Model type will be DT-601CG-AI-F-DC
e.g2) Choose analog voltage output (0 to 5V), 90°phase co ntrast input, sensor power supply DC24V.
Model type will be DT-601CG-RE-AV4-S24
INDEX
PAGE PAGE
1. Summary 2 17. BCD output 48
2. Specification 4 18. BCD input 49
3. Meter installation 6 19. Outline dimensional drawing 50
4. Names and functions of each parts in the front. 7 20. Terminal block label drawing 51
5. Connecting terminal block 9 21. Unit label drawing 52
6. Format of input circuit 12 22. Packing specifications 53
7. Format of output circuit 13 23. About noise protection 54
8. Setting up the dip switch 14 24. Trouble shooting 55
9. Setting menu 15
10. Initially set value and initialization 16
11. Contents of each mode and setting 17
12. Setting of preset value 43
13. Setting of display offset value 44
14. Mode protect function 45
15. Adjusting analog output 46
16. Sensitivity setting of sinusoidal input and sine curve input 47
function
*Option B and Option B1 cannot be chosen simultaneously.
Output Input
Sensor
power
supply
power
supply
DT-601CG
Model
name
Disp -
lay
90°
Input
P1
