SHIMPO DT-601CG - Manual (Page 24)

Mode# A input : Scaling data (Converter) setting
0 1 A B C D E F
0 1. 1 0 0 0
4digits value 0001 - 9999
( Do not set "0000" )
Function as scaling data (converter) for integrating measurement.
By setting the 4digit value and EXP value which is set by [Mode 02],
scaling factor per 1 signal can be set until 1x10
-9 - 9999.
[example]
Want to display integrating value as "L" using the flow sensor which is 2.5ml per 1 pulse.
Adjust the
prefered unit (L)
4digits value
EXP value
Mode 01
Mode 02
P22
